YE2 Series Electric Motor

Your Professional YE2 Series Electric Motor manufacturer!

Zhejiang Guangyue Motor Co., Ltd. is a high-tech enterprise specializing in the production of three phase asynchronous motors such as YE2 / YE3 series high efficient motors,marine motors,infrared bridge cutting motor, high pressure washer motors,variable frequency motors and brake motors.Our is one of China top professional infrared bridge cutting motor manufactures.

Why Choose Us

01/

Customized motors
With well-known vibration motor engineers from the mainland as the core technical research and development team, we have strong research and development capabilities and can meet the needs of customers' customized motor varieties.

02/

Quality assurance
Our company ensures that all products comply with IEC standards and are positioned at the forefront of global motor product standards. Our products are well received by domestic and foreign customers.

03/

Timely delivery
Our company has introduced multiple advanced production lines, with an annual output of about 200,000 units, strong production capacity and timely delivery, providing AC motors and motor control solutions for more than 2,000 customers in more than 60 industries.

04/

Professional team
Our team has successfully developed 28 series of more than 300 models of motors to meet the needs of different industries. The company has 45 patents, CE and ISO9001 certification.

Advantages of YE2 series electric motor

New structure:

YE2 series electric motors have novel structure and beautiful shape, which makes it not only powerful in industrial applications, but also has good visual effects.

Slight vibration,low noise:

YE2 series electric motors has a low noise and vibration level, which helps to improve the quality of the working environment and reduce the impact on the operator.

High insulation grade:

The YE2 series electric motor has a high insulation grade and is able to withstand higher operating temperatures, thus improving the service life and safety of the motor.

Wide range of applications：

YE2 series electric motors suitable for various industrial applications, such as machine tools, fans, water pumps and other general use places that require continuous operation.

Application of YE2 series electric motor

YE2 series electric motors can be widely used in various kinds of general use machines like fans,pumps,machining tools,compressors,transportation and so on,and can also be used in the hazardous areas of petroleum and chemical, steel plants, mining industry.

productcate-1-1

Parameters

Ambient temperature	-15℃≤0≤40℃
Altitude	Not exceeding 1000m
Rated voltage	380V or any voltage between 220-760V
Rated frequency	50Hz/60Hz
Power	0.75 kW~22 kW (1HP~30HP)
Poles	2P, 4P, 6P
Output Speed	3000RPM, 1500RPM, 1000RPM
Shaft Diameter	Φ19~Φ48
Efficiency Class	IE2
Protection class	IP54/IP55
Insulation class	F/H
Cooling method	lC0141
Duty	S1(continuous)
Connection	Star-connection for up to 3kw,delta-connection for 4kw and above.

Maintenance of YE2 series electric motor

01.

Cleaning:

Regularly remove dust and debris from the motor housing and cooling vents using compressed air or a soft brush. Wipe down the motor exterior with a damp cloth to remove dirt buildup.

02.

Lubrication:

Follow the manufacturer's schedule for relubricating the bearings with the specified grease type. Check for any signs of excessive grease leakage.

03.

Vibration Monitoring:

Regularly monitor motor vibration levels to identify potential bearing issues. Excessive vibration could indicate worn bearings or misalignment.

04.

Temperature Monitoring:

Monitor motor temperature to ensure it operates within the recommended range. High temperatures could indicate overload or malfunctioning cooling system.

Packaging & Shipping

productcate-1-1

FAQ

Q: What’s the minimum order quantity? How long is the delivery time?

A: Both MOQ and delivery time need to refer to the specific products. Usuall we deliver the motors in 10-45 days, please
contact our sales for details.

Q: Do you test all your goods before delivery?

A: Yes,Every motor 100% tested for the quality prior before shipment.

Q: What about the payment methods?

A: We accept T/T, L/C for big amount, and for small amount, you can pay us by PayPal, Western Union, Money gram, Escrow and etc.

Q: What about the shipping methods?

A: For urgent order and light weight, you can choose the following express: UPS, FedEx, TNT, DHL, EMS. For heavy weight, you can choose to deliver the goods by air or by sea to save cost.

Q: What are the three most common electrical problems in a electric motor?

A: The three most common electrical problems in an electric motor are: overheating due to overload, insulation breakdown leading to short circuits, and power supply issues like voltage imbalances or spikes; all of which can significantly impact the motor's functionality and lifespan.

Q: How do you keep an electric motor from overheating?

A: Keep it away from other sources of heat, give it plenty of space, and make sure that the ventilation holes are clear. When you start using your electric motor, remember to consistently monitor its temperature and performance for signs of overheating or deterioration.

Q: What keeps an electric motor cool?

A: Another common method for keeping electric motors cool is forced draught air cooling. Industrial motors often have an integral fan, mounted on the rear of the output shaft, so that it spins at the same rate as the driven load.

Q: Can you overload an electric motor?

A: An overload happens when an excessive amount of electricity passes through the system to the motor, which can lead to motor failure.

Q: How do you stop an electric motor from burning?

A: Always keep the motor clean. During operation, the motor is not allowed to have dust, water stains and other debris at least 3 meters around the air inlet to prevent the inside of the motor from being drawn, short-circuiting medium, or damage to the wire insulation.

Q: What factors should be considered when selecting a motor?

A: Considering factors such as speed, torque, duty cycle, load compatibility and maintenance requirements can help you select a compatible motor for your industrial facility.
